LV510305 | EasyPact CVS100B Circuit Breaker

Product Overview

The LV510305 is a high-performance circuit breaker from Schneider Electric’s EasyPact CVS100B series. Designed for industrial and commercial applications, this circuit breaker ensures reliable protection against overloads and short circuits. It features a thermal magnetic trip unit (TM-D) with a 63 A rating and a breaking capacity of 25 kA at 415 VAC.

Key Features

• Model: EasyPact CVS100B
• Part Number: LV510305
• Rated Current: 63 A
• Breaking Capacity: 25 kA at 415 VAC
• Trip Unit: Thermal Magnetic (TM-D)
• Number of Poles: 3P (3 Poles)
• Number of Protected Poles: 3d (3 Protected Poles)
• Voltage Rating: 415 VAC
• Mounting: Fixed
• Standards Compliance: IEC 60947-2, IEC 60898-1
• Terminal Type: Screw Clamp
• Operating Temperature: -25°C to +60°C
• Storage Temperature: -40°C to +85°C
• Mechanical Durability: 20,000 cycles
• Electrical Durability: 10,000 cycles

Applications

The EasyPact CVS100B circuit breaker is ideal for use in:

• Industrial control panels
• Commercial buildings
• Power distribution systems
• Motor protection circuits
• HVAC systems

Benefits

• High breaking capacity ensures reliable protection in demanding environments.
• Thermal magnetic trip unit provides precise overload and short-circuit protection.
• Compact design saves space in electrical panels.
• Complies with international standards for safety and performance.
• Durable construction ensures long service life.

Dimensions and Weight

• Width: 54 mm
• Height: 85 mm
• Depth: 70 mm
• Weight: 0.5 kg

Disclaimer

Specifications are subject to change without prior notice. Always refer to the official Schneider Electric documentation for the most accurate and up-to-date information.
